Wood pellet production line specifications:
1.Compact structure wood pellet production line.
2. Energy saving wood pellet production line.
3. Less investment wood pellet production line.
4. Easy operation and maintenance wood pellet production line.
| Model |
Power (kw) |
Capacity for wood pellets(kgs/h) |
Weight of the machine(kgs) |
Dimension of the machine (mm) |
| HY560 | 90 | 1000-1500 | 6500 | 2850x1300x2300 |
| HY580 | 110 | 1500-2000 | 7600 | 2250x1300x2260 |
| HY580S | 132 | 2000-2500 | 8500 | 2400x1400x2450 |
| HY760 | 160 | 3000-3500 | 10200 | 2450x1400x2550 |
| HY850 | 220 | 4000-6000 | 14500 | 3150x1500x2850 |
1.Vertical feed and directly in place.
2.Die static,the roller rotating,and material is centrifugal ,evenly around.
3.Double layers die,up and down dual use,cost efficiency,and also dual-uses,high energy saving.
4.Ring die,vertical structure ,in favor of the thermal cooling of granulation chamber
5.Separate discharge device,ensure the forming rate of pellets.
6.24hours working with automatic lubrication.
Materials for Wood Pellet Machine:
The raw material for this machine can be the food grain like corn, wheat and the crushed waste from agriculture for example, corn straw, groundnut shell, grass, wheat bran, sawdust, and animal manure and so on,
Services for the wood pellet production line:
1. We treat customers as gods, and provide considerate services from shipment to maintenance, including professional free training, guidance, installation,and debugging.
2. After sale, we provide one year's warranty. we will help to solve any mechanical problems in time. Also engineers are available to service overseas.
1. General questions to design the production line for you?
A: What is your raw materials? ( help us to confirm which machines will be used and to confirm the mould compression ratio of the pellet machine )
B. What is the moisture content of your raw material?( If the moisture is high, you need a dryer, becuase the suitable moisture content to enter pellet machine is 13-15% )
C. How many output capacity do you want per hour / month/ year?( help us to choose the suitable type and models of the machines for you )
2. How long is your guarantee?
5 yeas for the machine body,12 months for the motor and 1000-1500 working hours for the quick waering parts(die and rollers).
3. Will you send engineers to install the machines?
Of course. Our company has professional installation engineers team and specialized after-sale service team. When the machines arrive your factory, we will send our installation engineers to your factory at once. Our engineers will guide you to install the machines and training your workers how to operate the machines and mentain the machine.
4. Voltage requirement ?
Our machines can use 380V, 220V, 240V, 415V, 480V, and 50Hz, 60Hz or according to your requirements.
